Mediastinal lymph node cryobiopsy guided by endobronchial ultrasound: a comprehensive review of methods and outcomes
Review Article

Mediastinal lymph node cryobiopsy guided by endobronchial ultrasound: a comprehensive review of methods and outcomes

Shiwani Kamath, Abdullah Jahangir, Salim Daouk, Houssein A. Youness

Interventional Pulmonary Program, Section of Pulmonary, Critical Care and Sleep Medicine, Department of Medicine, University of Oklahoma Health Sciences Center and The Oklahoma City VA Health Care System, Oklahoma City, OK, USA

Contributions: (I) Conception and design: HA Youness; (II) Administrative support: None; (III) Provision of study materials or patients: None; (IV) Collection and assembly of data: S Kamath, A Jahangir, S Daouk; (V) Data analysis and interpretation: S Kamath, A Jahangir, S Daouk; (VI) Manuscript writing: All authors; (VII) Final approval of manuscript: All authors.

Correspondence to: Houssein A. Youness, MD, FCCP. Interventional Pulmonary Program, Section of Pulmonary, Critical Care and Sleep Medicine, Department of Medicine, University of Oklahoma Health Sciences Center and The Oklahoma City VA Health Care System, 800 Stanton L Young Blvd, Suite 8400, Oklahoma City, OK 73104, USA. Email: houssein-youness@ouhsc.edu.

Abstract: Endobronchial ultrasound-guided transbronchial needle aspiration (EBUS-TBNA) is the preferred initial method to diagnose and stage non-small cell lung cancer. EBUS-guided transbronchial cryobiopsy (EBUS-TBC) is a newer technique with the potential to address the limitations of EBUS-TBNA. Only a few studies have explored this technique and compared its diagnostic yield to that of EBUS-TBNA. This review aims to summarize the existing literature and provide insights into the optimal yield and technique for performing EBUS-TBC. A comprehensive search of the PubMed database was conducted for studies published up to May 2024 related to EBUS-TBC. The PICO framework (Participants, Intervention, Comparison, and Outcome) was used to evaluate the diagnostic yield, techniques employed, and associated complications. Eleven studies involving 857 patients were identified. In these trials, EBUS-TBC was performed after EBUS-TBNA at the same lymph node station. Techniques varied among bronchoscopists, with most procedures conducted under moderate sedation. The TBNA needle sizes ranged from 19G to 22G. Three trials used a needle knife for the initial mucosal incision, while others utilized the initial puncture site for cryoprobe insertion. Nine studies employed a 1.1-mm Erbe cryoprobe, with a median freezing time of 4 seconds (range, 3–7 seconds). The overall diagnostic yield of EBUS-TBC was 91.9%, compared to 76.6% for EBUS-TBNA alone, with EBUS-TBC yielding larger specimens. Mild bleeding was the most common complication reported. The addition of EBUS-TBC to EBUS-TBNA enhances the diagnostic yield without significantly increasing complications. The larger biopsy samples obtained can be particularly valuable for next-generation sequencing in lung cancer and for improving diagnostic accuracy in benign diseases and rare malignancies like lymphoma.

Keywords: Cryobiopsy; lymphadenopathy; mediastinum


Received: 14 August 2024; Accepted: 14 January 2025; Published online: 06 March 2025.

doi: 10.21037/med-24-39


Highlight box

Key findings

• The addition of endobronchial ultrasound-guided transbronchial cryobiopsy (EBUS-TBC) to endobronchial ultrasound-guided transbronchial needle aspiration (EBUS-TBNA) increased diagnostic yield without significantly increasing complications.

What is known and what is new?

• EBUS-TBNA is preferred for non-small cell lung cancer.

• The overall yield of EBUS-TBC was 91.9% compared to 76.6% for EBUS-TBNA alone. Mild bleeding was the most common complication.

What is the implication, and what should change now?

• EBUS-TBC provides a higher diagnostic yield and larger biopsy samples, which are especially valuable for next-generation sequencing in lung cancer and for improving diagnostic accuracy in benign diseases and rare malignancies such as lymphoma.


Introduction

The evaluation and diagnosis of mediastinal and hilar lymphadenopathy have evolved over the last several decades. Options for diagnosis offered are surgical methods, cervical or anterior mediastinoscopy (Chamberlain procedure), and less invasive methods, endobronchial ultrasound (EBUS) and endoscopic ultrasound (EUS). EBUS-guided transbronchial needle aspiration (EBUS-TBNA) is the preferred diagnostic modality for non-small cell lung cancer (NSCLC) and has been adopted as an initial diagnostic method per newer guidelines (1).

Depending on the underlying etiology, TBNA has varying results. For NSCLC, EBUS-TBNA has a sensitivity of 92.3% and a specificity of 100% (2). Molecular diagnostics, such as histological subtyping and genomic profiling in NSCLC, is possible in 86.5% of samples with EBUS-TBNA (3). In sarcoidosis, the diagnostic accuracy of EBUS-TBNA is 79% (4). The sensitivity of EBUS-TBNA in lymphoma is 66.2% (5).

Bronchoscopic cryobiopsy is a reasonably new development, gaining popularity in recent years. It uses compressed gas to cool surrounding tissue, known as the Joule-Thomson effect (6). The standard technique is to apply the probe adjacent to the target tissue, allow a temperature drop between –35 and –50 °C for several seconds to ensure adequate adhesion to surrounding tissues, and then remove the probe with attached tissue (7).

EBUS-guided transbronchial cryobiopsy (EBUS-TBC) for lymph node biopsy was first published in 2021. Compared to a yield by EBUS-TNBA of 53.2% for benign lesions and 25.0% for non-lung cancer tumors, the EBUS-TBC yield was 80.9% and 91.7%, respectively (8). The results suggest an advantage of cryobiopsy, especially in non-cancerous lymphadenopathy, and could potentially avoid the need for cervical mediastinoscopy. This paper serves to assess the literature regarding cryobiopsy, technique, as well as yield, outcome, and risk.


Methods

Literature search

A thorough literature search was conducted on PubMed, Cochrane, and Embase using the terms “EBUS cryobiopsy”, “transbronchial lymph node cryobiopsy”, and “lymph node cryobiopsy”.

The search was not limited to any region as long as an English translation was available. Articles from conferences were also included. There was no age filter applied for the patient population. Our cut-off date for this search was May 1, 2024.

Eligible studies included those in which bronchoscopic cryobiopsy probe was used to sample mediastinal or hilar lymph nodes and those that reported a diagnostic yield and safety outcomes.

Study selection

Two independent authors screened studies (A.J., S.K.) in regard to the title and abstract. Potential articles obtained from this initial review were then evaluated again by the full text by the same reviewers. Two authors individually assessed studies for bias utilizing the Quality Assessment Data Abstraction and Synthesis-2 (QUADAS-2). Studies were assessed in regard to patient selection, index test, reference standard, flow and timing. The reviewers then calculated the risk of bias and applicability concerns in each previously mentioned category as low, high, or unclear (Table 1).

Table 1

Studies looking at the yield of TBC

Author, year of publication Design No. Risk of bias/concern for applicability Intervention Wall incision Sedation Passes Cooling time (s)
Zhang, 2021 (8) RCT 197 Low/low Alternating passes with TBNA 22G/21G and cryo 1.1 High-frequency needle knife Moderate TBNA 4 passes with or without 3 cryo passes 7
Cheng, 2024 (9) RCT 155 Low/low TBNA 22G/21G with forceps vs. TBNA with cryo 1.1 High-frequency needle knife Moderate TBNA 4 passes followed by 3 forceps or 1 cryo 7
Fan, 2023 (10) RCT 271 Low/low 4 TBNA followed by one cryo 1.1 High-frequency needle knife Moderate TBNA 4 passes with or without 3 cryo passes 7
Poletti, 2024 (11) Observational 48 Low/low 22G TBNA followed by cryo 1.1 Needle puncture site General TBNA followed by 1 cryo 6
Genova, 2022 (12) Prospective 5 High/low 19G TBNA followed by cryo 1.1 Needle puncture site Moderate 3 TBNA followed by cryo 2 passes 4
Gershman, 2022 (13) Prospective 27 Low/low 22G TBNA followed by cryo 1.1/1.7 Needle puncture site or YAG laser Moderate 2–4 TBNA followed by cryo 2–4 passes 3–4
Gonuguntla, 2021 (14) Prospective 4 High/low 22/21/19G TBNA followed by cryo 1.1 Needle puncture site General TBNA followed by cryo 1–2 passes 3
Ariza-Prota, 2022 (15) Prospective 4 High/low 22G TBNA followed by cryo 1.1 Needle puncture site Moderate 4 TBNA followed by cryo 3 passes 3
Ariza-Prota, 2023 (16) Prospective 50 High/low 22G TBNA followed by cryo 1.1 Needle puncture site Moderate TBNA followed by cryo 3 passes 4
Salcedo, 2023 (17) Case series 50 Low/high 22G TBNA followed by cryo 1.1 Needle puncture site Moderate 2 TBNA followed by cryo average of 4 passes 4
Maturu, 2024 (18) Prospective 46 Low/low 19G TBNA followed by cryo 1.1 Needle Puncture site Moderate 3 TBNA passes, and if ROSE negative cryo with 4 passes 5–6

G, gauge; RCT, randomized controlled trial; ROSE, rapid on-site evaluation; TBNA, transbronchial needle aspiration; TBC, transbronchial cryobiopsy; YAG, yttrium aluminum garnet laser.

Data extraction and analysis

Data extraction was performed utilizing pre-specified tables of baseline characteristics, the diagnostic yield of cryobiopsy, needle size, number of cryo-biopsies performed, cooling time, wall incision techniques, and complications.


Results

The literature search yielded 45 articles. After excluding ten duplicates, 35 articles were selected based on their titles and abstracts. After this evaluation, 16 studies were found to be possibly useful for our review. Subsequently, the full texts of these articles were reviewed. Five articles were then excluded, the reason listed are as follows: review papers (n=1), articles without relevant outcomes (n=2), and abstracts and case reports (n=2) (Figure 1). A total of 11 studies were included in the final review (Table 1) (8-18).

Figure 1 Flowchart of the search process for the review related to EBUS cryobiopsy of hilar and mediastinal lymph nodes. EBUS, endobronchial ultrasound.

Reported technique

The procedure for performing lymph node cryobiopsy varies among bronchoscopists. Nine studies reported procedures performed under moderate sedation, and two reported using general anesthesia for the performed procedures. Only one study utilized a rigid tracheoscope for intubation for the procedure (11). After a surveillance bronchoscopy and lymph node identified by EBUS, almost all studies performed a TBNA to create a puncture site for the cryoprobes to enter the mediastinal space (Figure 2). Needle gauge size varied; most studies used 22G, but 19G and 21G were also used. Cheng et al. also used forceps with TBNA to create an incisional track (9). Two studies used a high-frequency needle knife to make a small incision adjacent to the target before probe placement. The knife was then removed and replaced with a probe (8,10).

Figure 2 Execution of EBUS-guided lymph node cryobiopsy. (A) Bronchial view of mediastinal space puncture-site access after TBNA. (B) Cryoprobe entering the puncture site under direct visualization. (C) Direct visualization via EBUS of cryoprobe entering lymph node. (D) Frozen tissue surrounding the cryoprobe tip after the probe is removed en-bloc. These images are published with the patient’s consent. EBUS, endobronchial ultrasound; TBNA, transbronchial needle aspiration.

Erbe offers three sizes of single-use, flexible cryoprobes—1.1, 1.7, and 2.4 mm (19,20). All studies were performed with a cryoprobe size of 1.1 mm, except for one by Gershman et al., who also used the 1.7-mm probe (13). The probe was advanced through the working channel into the lesion under direct visualization and further guided by real-time ultrasound imaging. Optimal location was left to the discretion of the proceduralists, who generally avoided areas with abundant blood flow or massive necrosis. After placing the cryoprobe, it was activated to cool down with nitrous oxide. Six studies froze tissue for 3 to 4 seconds (12-17), two studies for 5 to 6 seconds (11,18), and the remaining studies froze tissue for 7 seconds (8-10).

In all studies, the operator removed the bronchoscope and cryoprobe with attached frozen biopsy en-bloc from the airway. Since the sample from cryobiopsy is significantly larger than the working channel of the bronchoscope, it cannot be extracted through the channel. Samples were retrieved in saline and immediately placed in formalin. Rapid on-site evaluation (ROSE) was not routinely used. Compared to TBNA, cryobiopsy delivered larger biopsy sizes (0.46–0.47 vs. 0.18–0.20 mm) (16). Cheng et al. obtained cryobiopsy samples of 8.1 mm2 compared to forceps biopsy sizes of 2.1 mm2 (9).

The overall procedural time varied among studies, but performing cryobiopsy took additional time. Velasco-Albendea et al. and Ariza-Prota et al. reported 10 minutes to obtain a cryobiopsy in addition to the time taken to perform EBUS (16,21). Fan et al. reported a difference in total time between EBUS-TBNA alone or with the addition of EBUS-TBC as 17.0 vs. 22.3 minutes (10). Zhang and colleagues reported the difference between performing EBUS-TBNA and EBUS-TBC as 2 minutes (8). Oikonomidou found it took 20–30 minutes to perform EBUS-TBNA but 30–40 minutes to perform EBUS-TBC (22). However, lymph node cryobiopsy took less time than lymph node forceps biopsy (1.7 vs. 3.3 minutes) (9).

Indications & contraindications

Any lymph node traditionally accessed through the bronchial tree is amenable to cryobiopsy (i.e., stations 2, 4, 7, 10 & 11). All patients needed to meet the criteria for bronchoscopy and EBUS. Mediastinal cysts or abscesses are usually excluded. The standard size of lymph nodes biopsied was ≥1 cm. Fan et al. did not specify size limitation, but the average diameter of lymph nodes biopsied via cryobiopsy was 2.0 cm (10).

In some studies, the surrounding vascularity was measured via the Doppler-mode blood flow via ultrasound and categorized per Nakajima et al.’s grading system: grade 0: no blood flow or minimal flow; grade I: a few vessels directed toward the center of the lesion; grade II: punctiform or rod-shaped flow signals or vessels found as a long strip of a curve; and grade III: rich flow with at least five vessels with different diameters and a twist or helical-flow signal (23). For lesions that were grade III, indicating significant blood supply, another node or site was selected to limit complications (10).

Complications

The most common complication was bleeding. Bleeding was classified per a previously published scale by Ernst et al. and Yarmus et al. as follows: grade 0: no suctioning required; grade 1: bleeding requiring suctioning and wedging for 2 minutes or less; grade 2: bleeding requiring wedging for at least 3 minutes; grade 3: bleeding requiring instillation of epinephrine or iced saline; and grade 4: bleeding requiring hemodynamic support including transfusion of blood products, selective mainstem intubation, bronchial blocker placement, hospital admission, or other surgical intervention (24,25). Most studies reported minor bleeding (grade 0–1). Pneumothorax or pneumomediastinum was another reported complication noted on post-procedural radiography. These occurred at a rate of <2% and resolved without further intervention. Salcedo Lobera et al. reported that out of the 50 patients involved in their study, two patients experienced hypoxemia requiring an increase in oxygen supplementation, and 1 developed a vocal cord hematoma; however, all patients were discharged home on the same day as the procedure (17). None of the above complications were statistically significant compared to the control group, suggesting that cryobiopsy offers no significant additional procedural risk.


Yield

Overall yield

Several recent studies have compared the efficacy of EBUS-TBC vs. EBUS-TBNA (Table 1).

The overall mean and median yield of EBUS-TBC reported in the studies was 91.9% and 92.4% compared to 76.6% and 78.2% or EBUS-TBNA alone with a corresponding range of 60–100% and 54–87.5% respectively (Table 2). One study looked at the yield of cryobiopsy when the ROSE of the EBUS-TBNA was indeterminate or nondiagnostic. Cryobiopsy achieved diagnosis in 33 of 46 cases compared to 19 of 46 patients with EBUS-TBNA alone (18).

Table 2

Overall yield for EBUS-TBC and EBUS-TBNA

Author, year Cryobiopsy TBNA
Population Yield Percentage Population Yield Percentage
Cheng, 2024 (9) 154 141 91.6 154 118 76.6
Zhang, 2021 (8) 194 178 91.8 194 155 79.9
Fan, 2023 (10) 136 126 92.6 135 109 80.7
Poletti, 2024 (11) 48 46 95.8 48 26 54.2
Genova, 2022 (12) 5 3 60.0 5 4 80.0
Gershman, 2022 (13) 24 20 83.3 24 21 87.5
Gonuguntla, 2021 (14) 4 4 100.0 4 3 75.0
Ariza-Prota, 2022 (15) 4 4 100.0 4 3 75.0
Ariza-Prota, 2023 (16) 50 48 96.0 50 41 82.0
Salcedo, 2023 (17) 50 45 90.0 50 32 64.0

EBUS-TBC, endobronchial ultrasound-guided transbronchial cryobiopsy; EBUS-TBNA, endobronchial ultrasound-guided transbronchial needle aspiration.

Benign etiologies

For benign etiologies of lymphadenopathy, including sarcoidosis and tuberculosis, cryobiopsy reportedly had a higher yield in several studies (8-10,14,16). The overall median reported yield for benign lymphadenopathy diagnosis with EBUS-TBC was 94% compared to 60% with EBUS-TBNA alone with a range of 78.7–100% and 53.2–100% respectively (Table 3).

Table 3

Yield in benign pathology

Study No. of patients with benign pathology Cryobiopsy yield (%) TBNA yield (%)
Cheng, 2024 (9) 47 78.7 59.6
Zhang, 2021 (8) 47 80.9 53.2
Fan, 2023 (10) 48 94 66.7
Gonuguntla, 2021 (14) 2 100 100
Ariza-Prota, 2023 (16) 12 100 60

TBNA, transbronchial needle aspiration.

Malignant etiologies

The overall yield for detection of malignant lesions overall was reportedly 94.36% with EBUS-TBC and 86.85% with EBUS-TBNA. The diagnostic yield for common lung tumors was 95.21% with EBUS-TBC and 92.67% with EBUS-TBNA (8-12,14-17). EBUS-TBC outperformed EBUS-TBNA significantly in detection of uncommon tumors in the lung with reported yield of 90.14% with EBUS-TBC and 57.75% with EBUS-TBNA (8-12).

Lymphoma

Cheng et al. reported successful lymphoma diagnosis in 13 out of 15 cases using EBUS-TBC compared to 11 with forceps biopsy (9). Fan et al. included ten patients with lymphoma with EBUS-TBC, providing the diagnosis in 8 patients compared to 5 with EBUS-TBNA (10). Zhang reported an 88% (7/8) yield for lymphoma vs. 13% for TBNA alone (8). Ariza-Prota et al. reported 4 cases of lymphoma in their cohort, and all of them were diagnosed with EBUS-TBC (16). In the study by Maturu et al., EBUS-TBC was able to identify two additional cases of lymphoma after negative ROSE with EBUS-TBNA (18).

Sarcoidosis

Cheng et al. reported a yield of 92% for sarcoidosis with EBUS-TBC (11/12) compared to 75% with EBUS-TBNA alone (9). Zhang et al. reported a 100% yield (15/15) for sarcoidosis with EBUS-TBC compared to 66% with TBNA (8). Fan et al. included 16 patients in their cohort diagnosed with sarcoidosis with an EBUS-TBC yield of 100% compared to 75% for TBNA (10). Poletti et al. reported 13 patients diagnosed with sarcoidosis with EBUS-TBC compared to 11 with EBUS-TBNA (11). Gershman et al. and Gonuguntla et al. reported 11 and 1 case of sarcoidosis testing positive both with EBUS-TBC and EBUS-TBNA (13,14). Maturu et al. reported 2 cases of sarcoidosis detected with EBUS-TBC that were not detected with TBNA (18). Only one study by Salcedo Lobera et al. reported a higher detection rate with EBUS-TBNA (4 cases) than EBUS-TBC (2,17).

Molecular testing

Three studies compared the ability to run molecular testing on the available specimens. Zhang et al. reported that 93% of cryo samples were adequate for molecular testing compared to 73% for TBNA (8). Fan et al. reported 97% of samples with cryo as adequate for molecular and programmed death-ligand (PD-L) testing compared to 79% with TBNA (10). Ariza-Prota et al. and Genova et al. reported all samples as adequate for molecular testing (12,16).


Discussion

Cryobiopsy of pulmonary tissue is an established technique to obtain a pathological diagnosis in interstitial lung disease. It has also been validated in tumor debulking, foreign body extraction, and endobronchial tissue diagnosis. Cryobiopsy for mediastinal and hilar lymphadenopathy has gained popularity over the past few years. The need for targeted treatments, including immunotherapy and chemotherapy in the case of NSCLC, requires a significant amount of tissue to obtain molecular and genetic profiles of the tumors. Similarly, in the case of benign lung diseases, a greater sample size might be needed to delineate the underlying architecture of the lymph node, making EBUS-TBC an attractive option for diagnosis.

Multiple methods of introducing the cryoprobe have been described, and practice varies across providers, but generally, the results have been excellent, and complication rates remain low. Initial studies (8-10) used the high-frequency knife to create a hole in the airway wall to access the lymph node. This technique may require expertise. However, most recent studies have reported using the hole already created by the TBNA to introduce the cryoprobe, which might have an easier learning curve for experienced EBUS operators.

Cryobiopsy outperformed TBNA in most studies for diagnosis of sarcoidosis and pneumoconiosis. One study (17) reported significantly higher cases of proliferative histiocytosis diagnosed with the use of cryobiopsy. It also performed remarkably well in diagnosing benign etiologies of lymphadenopathy compared to TBNA alone, making it an attractive option when such a diagnosis is clinically suspected.

Cryobiopsy also outperformed EBUS-TBNA for detection of malignant lesions, regardless of if they were common or uncommon lung tumors. Cryobiopsy also obtained sufficient tissue for molecular testing as overall sample adequacy was reportedly around 95%. Similarly, the detection and tumor characterization rates for lymphoma were significantly higher in the cryobiopsy group, with an overall yield of over 90%. This marks a remarkable improvement on TBNA, which in literature has a reported sensitivity of around 77% (26). This increase in yield might be explained by the need for histologic analysis rather than cytologic analysis needed for the characterization of lymphomas, which might not be possible with samples from TBNA.

Since the end-date of our literature review, Romero et al. and Chandragiri et al. have since published a comprehensive review of EBUS-TBC (27,28). However, these studies included case reports, which we did not include, and overall fewer randomized controlled trials. These studies, when read along ours, provide a broader literature review.


Limitations

One major limitation is the inconsistent lymph node size criteria used across studies. Most studies included in this review utilized a size threshold of greater than 1 cm for biopsies, which contrasts with the widely accepted clinical guidelines recommending biopsy for nodes larger than 0.5 cm in EBUS (29). This divergence introduces selection bias and limits the generalizability of the findings, especially for smaller lymph nodes that are frequently biopsied during standard EBUS procedures. The complication rate could be higher when aiming at doing a cryobiopsy of a smaller lymph node.

The adequacy of next-generation sequencing in EBUS-TBNA may be underestimated in this review. Our article compared studies that did molecular testing in the same lymph node between EBUS-TBNA and EBUS-TBC. The largest one of them by Zhang et al. reported a difference of 93% vs. 73% for the ability to run molecular testing on EBUS-TBC vs. EBUS-TBNA respectively (8). The other two trials were of smaller number and included 5 or less patients. There was also no standardized definition for adequacy of molecular testing. This is in contrast to systematic reviews which report higher rates of adequacy (94.5% for EGFR and 94.9% for ALK mutations) by EBUS-TBNA (30).

Lastly, the financial implications of EBUS-TBC are not well reported. There were no mentions of cost analysis in the listed studies.


Conclusions

Overall, cryobiopsy is a safe procedure with excellent results that can be used as an adjunct to already practiced techniques. The benefit of preventing repeat procedures with better yield from the addition of EBUS-TBC might compensate for the additional procedural time required. There is a need for standardization of the procedure techniques and training structure. Large multi-center studies are needed to integrate cryobiopsy into algorithms for mediastinal node sampling.


Acknowledgments

None.


Footnote

Peer Review File: Available at https://med.amegroups.com/article/view/10.21037/med-24-39/prf

Funding: None.

Conflicts of Interest: All authors have completed the ICMJE uniform disclosure form (available at https://med.amegroups.com/article/view/10.21037/med-24-39/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.


References

  1. De Leyn P, Lardinois D, Van Schil PE, et al. ESTS guidelines for preoperative lymph node staging for non-small cell lung cancer. Eur J Cardiothorac Surg 2007;32:1-8. [Crossref] [PubMed]
  2. Herth FJ, Ernst A, Eberhardt R, et al. Endobronchial ultrasound-guided transbronchial needle aspiration of lymph nodes in the radiologically normal mediastinum. Eur Respir J 2006;28:910-4. [Crossref] [PubMed]
  3. Karadzovska-Kotevska M, Brunnström H, Kosieradzki J, et al. Feasibility of EBUS-TBNA for histopathological and molecular diagnostics of NSCLC-A retrospective single-center experience. PLoS One 2022;17:e0263342. [Crossref] [PubMed]
  4. Agarwal R, Srinivasan A, Aggarwal AN, et al. Efficacy and safety of convex probe EBUS-TBNA in sarcoidosis: a systematic review and meta-analysis. Respir Med 2012;106:883-92. [Crossref] [PubMed]
  5. Labarca G, Sierra-Ruiz M, Kheir F, et al. Diagnostic Accuracy of Endobronchial Ultrasound Transbronchial Needle Aspiration in Lymphoma. A Systematic Review and Meta-Analysis. Ann Am Thorac Soc 2019;16:1432-9. [Crossref] [PubMed]
  6. Lin CK, Ruan SY, Fan HJ, et al. Using cryoprobes of different sizes combined with cone-beam computed tomography-derived augmented fluoroscopy and endobronchial ultrasound to diagnose peripheral pulmonary lesions: a propensity-matched study. Respir Res 2024;25:65. [Crossref] [PubMed]
  7. Wener RRL, Van Schil PE. Evolving diagnostic techniques in mediastinal lymphadenopathy: is mediastinal cryobiopsy the new kid on the block? Eur Respir J 2021;58:2101496. [Crossref] [PubMed]
  8. Zhang J, Guo JR, Huang ZS, et al. Transbronchial mediastinal cryobiopsy in the diagnosis of mediastinal lesions: a randomised trial. Eur Respir J 2021;58:2100055. [Crossref] [PubMed]
  9. Cheng TL, Huang ZS, Zhang J, et al. Comparison of cryobiopsy and forceps biopsy for the diagnosis of mediastinal lesions: A randomised clinical trial. Pulmonology 2024;30:466-74. [Crossref] [PubMed]
  10. Fan Y, Zhang AM, Wu XL, et al. Transbronchial needle aspiration combined with cryobiopsy in the diagnosis of mediastinal diseases: a multicentre, open-label, randomised trial. Lancet Respir Med 2023;11:256-64. [Crossref] [PubMed]
  11. Poletti V, Petrarulo S, Piciucchi S, et al. EBUS-guided cryobiopsy in the diagnosis of thoracic disorders. Pulmonology 2024;30:459-65. [Crossref] [PubMed]
  12. Genova C, Tagliabue E, Mora M, et al. Potential application of cryobiopsy for histo-molecular characterization of mediastinal lymph nodes in patients with thoracic malignancies: a case presentation series and implications for future developments. BMC Pulm Med 2022;22:5. [Crossref] [PubMed]
  13. Gershman E, Amram Ikan A, Pertzov B, et al. Mediastinal "deep freeze"-transcarinal lymph node cryobiopsy. Thorac Cancer 2022;13:1592-6. [Crossref] [PubMed]
  14. Gonuguntla HK, Shah M, Gupta N, et al. Endobronchial ultrasound-guided transbronchial cryo-nodal biopsy: a novel approach for mediastinal lymph node sampling. Respirol Case Rep 2021;9:e00808. [Crossref] [PubMed]
  15. Ariza-Prota MA, Pérez-Pallarés J, Fernández-Fernández A, et al. Transbronchial Mediastinal Cryobiopsy in the Diagnosis of Mediastinal Lymph Nodes: A Case Series - How to do it. Arch Bronconeumol 2022;58:718-21. [Crossref] [PubMed]
  16. Ariza-Prota M, Pérez-Pallarés J, Fernández-Fernández A, et al. Endobronchial ultrasound-guided transbronchial mediastinal cryobiopsy in the diagnosis of mediastinal lesions: safety, feasibility and diagnostic yield - experience in 50 cases. ERJ Open Res 2023;9:00448-2022. [Crossref] [PubMed]
  17. Salcedo Lobera E, Codeso FMP, Casado Miranda E. Endobronchial ultrasound-guided transbronchial mediastinal cryobiopsy: series of 50 cases. Rev Clin Esp (Barc) 2023;223:578-81. [Crossref] [PubMed]
  18. Maturu VN, Prasad VP, Vaddepally CR, et al. Endobronchial Ultrasound-guided Mediastinal Lymph Nodal Cryobiopsy in Patients With Nondiagnostic/Inadequate Rapid On-site Evaluation: A New Step in the Diagnostic Algorithm. J Bronchology Interv Pulmonol 2024;31:2-12. [Crossref] [PubMed]
  19. Anon. Instruments and accessories No Year. Available online: https://us.erbe-med.com/us-en/products/cryosurgery/cryoprobes-for-erbecryor-2/
  20. Erbe. Instruments and accessories: 2024 Erbe Elektromedizin GmbH 2024. Available online: https://us.erbe-med.com/us-en/products/cryosurgery/cryoprobes-for-erbecryor-2/
  21. Velasco-Albendea FJ, Cruz-Rueda JJ, Gil-Belmonte MJ, et al. The Contribution of Mediastinal Transbronchial Nodal Cryobiopsy to Morpho-Histological and Molecular Diagnosis. Diagnostics (Basel) 2023;13:3476. [Crossref] [PubMed]
  22. Oikonomidou R, Petridis D, Kosmidis C, et al. Cryo-Biopsy versus 19G needle versus 22G needle with EBUS-TBNA endoscopy. J Cancer 2022;13:3084-90. [Crossref] [PubMed]
  23. Nakajima T, Anayama T, Shingyoji M, et al. Vascular image patterns of lymph nodes for the prediction of metastatic disease during EBUS-TBNA for mediastinal staging of lung cancer. J Thorac Oncol 2012;7:1009-14. [Crossref] [PubMed]
  24. Ernst A, Eberhardt R, Wahidi M, et al. Effect of routine clopidogrel use on bleeding complications after transbronchial biopsy in humans. Chest 2006;129:734-7. [Crossref] [PubMed]
  25. Yarmus L, Akulian J, Gilbert C, et al. Cryoprobe transbronchial lung biopsy in patients after lung transplantation: a pilot safety study. Chest 2013;143:621-6. [Crossref] [PubMed]
  26. Grosu HB, Iliesiu M, Caraway NP, et al. Endobronchial Ultrasound-Guided Transbronchial Needle Aspiration for the Diagnosis and Subtyping of Lymphoma. Ann Am Thorac Soc 2015;12:1336-44. [Crossref] [PubMed]
  27. Romero AO, Kho SS. Transbronchial mediastinal cryobiopsy—literature review and practice recommendations. AME Med J 2024;9:35. [Crossref]
  28. Chandragiri PS, Tayal A, Mittal S, et al. Utility and safety of endobronchial ultrasound-guided transbronchial mediastinal cryobiopsy (EBUS-TMC): A systematic review and meta-analysis. Lung India 2024;41:288-98. [Crossref] [PubMed]
  29. Torre M, Reda M, Musso V, et al. Diagnostic accuracy of endobronchial ultrasound-transbronchial needle aspiration (EBUS-TBNA) for mediastinal lymph node staging of lung cancer. Mediastinum 2021;5:15. [Crossref] [PubMed]
  30. Labarca G, Folch E, Jantz M, et al. Adequacy of Samples Obtained by Endobronchial Ultrasound with Transbronchial Needle Aspiration for Molecular Analysis in Patients with Non-Small Cell Lung Cancer. Systematic Review and Meta-Analysis. Ann Am Thorac Soc 2018;15:1205-16. [Crossref] [PubMed]
